Bike Build Specs
CALL 860-537-4306 or E-mail techinfo@avalanchedownhillracing.com us for more details and help
LET AVALANCHE SUSPENSION HELP CREATE YOUR BUILD
All data is our best estimate based on the information provided online
| MODEL VERSION YEARS | 2020- |
|---|---|
| TIRE SIZE | 27.5 or 29 |
| FRAME MATERIAL | ALLOY (alum) |
| BIKE WEIGHT (lbs) | 37 |
| SHOCK SIZE | 250 x 75 |
| TRAVEL MM | 203 |
| UPPER REDUCER | 20.0 x 8.0 |
| LOWER REDUCER | 40.0 x 8.0 |
| LINKAGE | FLOATING PIVOT UPPER/LOWER |
| AVERAGE LEVERAGE | 2.71 |
| STARTING LEVERAGE | 3.0 |
| SAG POINT LEVERAGE | 2.85 |
| ENDING LEVERAGE | 2.45 |
| PROGRESSION % | 18.33 |
| LEVERAGE CURVE | PL
|
| Installed Pictures | Installed Views |
| SHOCK TUNE | PROGRESSIVE PL |
| OEM SHOCK | Ohlins TTX |
| UPGRADE OPTION | BOMBER CR |
| UPGRADE OPTION | AVALANCHE WOODIE |
| SUGGESTED SHOCK SPRING | 350,350,400,450,500,550, |
| HEAD TUBE ANGLE | 63.0 |
| RECOMMENDED FORK TRAVEL | 203 |
| OEM FORK | Ohlins |
| UPGRADE OPTION CARTRIDGE/SPRING | Fox 40 HYBRID |
| UPGRADE OPTION CARTRIDGE/SPRING | ROCKSHOX BOXXER HYBRID |
SUGGESTED FORK SPRING WITH OUR CARTRIDGE | 25,30,35,35,40,45, |
| COMMENTS | CBF, 190 uses 250 x 70, best estimate for leverage |
| COMMENTS | mullet possible |
